INCANDESCENT | Reflector |
 STR50 (Clear / Frosted) |
 STR63 (Clear / Frosted) |
 STR80 (Clear / Frosted) |
| Model No. | Energy Class |
Lumen | Intensity | Wattage | Color Temperature |
Lifetime | CRI | Voltage | Beam Angle |
Dimmable | Base |
| STR50 | E | 107 lm | 120 cd | 25W | 2700K | 1000 hr | ≥100 | 220~240V | 38° | Yes | E14 |
| 208 lm | 350 cd | 40W | |||||||||
| STR63 | E | 208 lm | 350 cd | 40W | 2700K | 1000 hr | ≥100 | 220~240V | 60° | Yes | E27 / B22 |
| 360 lm | 650 cd | 60W | |||||||||
| STR80 | E | 360 lm | 650 cd | 60W | 2700K | 1000 hr | ≥100 | 220~240V | 38° | Yes | E27 / B22 |
| 695 lm | 1000 cd | 100W |
Dimension |
|||||||||||||||||||
| Model No. | E12 | E14 | E26 | E27 | B15d | B22 | |||||||||||||
| STR50 | Ø50 x 85H mm | ||||||||||||||||||
| STR63 | Ø63 x 102H mm | Ø63 x 101H mm | |||||||||||||||||
| STR80 | Ø80 x 114H mm | Ø80 x 112.5H mm | |||||||||||||||||
Tolerance of product dimension : Lenght ± 2mm/Diameter ± 0.5mm / Test data based on 220-240V |
 |
